POLYCRYSTALLINE SOLAR PANEL 60 W 12 V

SOL60P
Popular item
Options (8)
Support
User manual
Support
solar powered
Compare

Robust all-purpose solar module with high efficiency solar cell.

Features

  • high module efficiency and stable power output based on leading process technology
  • outstanding electrical performance under high temperature conditions or low irradiance conditions
  • easy of installation and all-weather applications
  • for: small solar installations (caravan, camper...)

Specifications

  • maximum power (Pmax): 60 W
  • voltage at Pmax (Vmp): 17.6 V
  • current at Pmax (Imp): 3.46 A
  • open-circuit voltage (Voc): 22 V
  • short-circuit current (Isc): 3.66 A
  • temperature coefficient of Voc: -(0.40 ± 0.05) % / °C
  • temperature coefficient of Isc: (0.065 ± 0.01) % / °C
  • temperature coefficient of power: -(0.5 ± 0.05) % / °C
  • NOCT: 47 ± 2 °C
  • operating temperature: -40 °C to +85 °C
  • maximum system voltage: 600 V DC
  • power tolerance: ± 3 %
  • cells: polycrystalline silicon solar cell
  • number of cells and connections: 36 (4 x 9)
  • module dimension: 670 mm x 650 mm x 30 mm
  • weight: 4.6 kg (10.14 lbs)
