POLYCRYSTALLINE SOLAR PANEL 30 W 12 V

SOL30P
Popular item
Support
User manual
Support
solar powered
Compare

Robust all-purpose solar module with high efficiency solar cell.

Features

  • high module efficiency and stable power output based on leading process technology
  • outstanding electrical performance under high temperature conditions or low irradiance conditions
  • easy of installation and all-weather applications
  • for: small solar installations (caravan, camper...)

Specifications

  • maximum power (Pmax): 30 W
  • voltage at Pmax (Vmp): 17.6 V
  • current at Pmax (Imp): 1.71 A
  • open-circuit voltage (Voc): 22 V
  • short-circuit current (Isc): 1.81 A
  • temperature coefficient of Voc: -(0.40 ± 0.05) % / °C
  • temperature coefficient of Isc: (0.065 ± 0.01) % / °C
  • temperature coefficient of power: -(0.5 ± 0.05) % / °C
  • NOCT: 47 ± 2 °C
  • operating temperature: -40 °C to +85 °C
  • maximum system voltage: 600 V DC
  • power tolerance: ± 3 %
  • cells: polycrystalline silicon solar cell
  • number of cells and connections: 36 (2 x 18)
  • module dimension: 650 mm x 350 mm x 30 mm (1.18")
  • weight: 3.1 kg (7.68 lbs)
This item cannot be sold in: Canada

All registered trademarks and trade names are properties of their respective owners and are used only for the clarification of the compatibility of our products with the products of the different manufacturers.
Due to constant product improvements the actual product appearance might differ from the shown images. Product images are for illustrative purposes only.
