SWITCHING POWER SUPPLY - SINGLE OUTPUT - 50 W - 5 V - CLOSED FRAME - FOR PROFESSIONAL USE ONLY

RS-50-5
Support
Downloads (2)
Warranty
Support
Compare

Features

  • universal AC input / full range
  • protections: short circuit / overload / over voltage
  • cooling by free air convection
  • LED indicator for power on
  • 100% full load burn-in test
  • 105 °C extended liftetime electrolytic capacitors
  • withstands 300 VAC surge input for 5 seconds
  • high operating temperature up to 70°C
  • withstands 5 G vibration test
  • no load power consumption < 0.5 W
  • high efficiency, long life and high reliability
  • 3 years warranty
  • for professional use only
  • This device must be installed by a qualified person.

Specifications

  • output:
    • DC voltage: 5 V
    • rated current: 10 A
    • current range: 0 ~ 10 A
    • rated power: 50 W
    • ripple & noise (max.): 80 mVp-p
    • voltage adj. range: 4.75 ~ 5.5 V
    • voltage tolerance: ± 2.0%
    • line regulation: ± 0.5%
    • load regulation: ± 1.0%
    • set up, rise time: 500 ms, 30 ms / 230 VAC 1200 ms, 30 ms / 115 VAC at full load
    • hold up time (typ.): 60 ms / 230 VAC 14 ms / 115 VAC at full load
  • input:
    • voltage range: 88 ~ 264 VAC 125 ~ 373 VDC (withstand 300 VAC surge for 5 sec. without damage)
    • frequency range: 47 ~ 63 Hz
    • efficiency (typ.): 83 %
    • AC current (typ.): 1.3 A / 115 VAC 0.8 A / 230 VAC
    • inrush current (typ.): cold start 33 A / 230 VAC
    • leakage current: < 2 mA / 240 VAC
  • protection:
    • overload:
      • 110 ~ 150% rated output power
      • protection type: hiccup mode, recovers automatically after fault condition is removed
    • over voltage:
      • 5.75 ~ 6.75 V
      • protection type: hiccup mode, recovers automatically after fault condition is removed
  • environment:
    • working temperature: -25 ~ +70°C (refer to "derating curve")
    • working humidity: 20 ~ 90% RH non-condensing
    • storage temperature, humidity: -40 ~ +85°C , 10 ~ 95% RH
    • temperature coëfficient: ± 0.03 % / °C (0~50°C)
    • vibration: 10 ~ 500 Hz, 5 G 10 min./ 1 cycle, period for 60 min. each along X, Y, Z axes
  • safety & EMC:
    • safety standards: UL60950-1, TUV EN60950-1 approved
    • withstand voltage: I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
    • isolation resistance: I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25°C / 70% RH
    • EMC emission: compliance to EN55022 (CISPR22) class B, EN61000-3-2,-3
    • EMC immunity: compliance to EN61000-4-2,3,4,5,6,8,11; EN61000-6-2 (EN50082-2), heavy industry level, criteria A
  • others:
    • MTBF: 228 Khrs min. MIL-HDBK-217 F (25°C )
    • dimension: 99 * 97 * 36 mm (l * w * h)
    • packing: 0.41 kg; 45 pcs / 19.5 kg / 0.9 CUFT
