WATERPROOF FEMALE MULTI-PIN CONNECTOR - 3 PINS
- without strain relief (SR)
- solder connections
- with coupling nut
- to be used with: WATERPROOF MALE MULTI-PIN CONNECTOR - 3 PINS
- current rating: 10 A
- contact resistance: < 5 mohm
- insulation resistance: > 500 mohm @ 500 Vdc
- breakdown voltage: 1000 V
- max. voltage rating: 24 V
- IP rating: IP68, 10 m water, 2 weeks
- durability: > 3000 plug/unplug cycles
- body: nylon + GF UL94V-0 1/16"
- contact: brass C2680 & C17200 4µ" - 20µ" gold plated
- sealing: EPDM
- number of contacts: 3
- type: female
