DUAL PLL WIRELESS 8-CHANNEL UHF MICROPHONE SYSTEM WITH LCD DISPLAY

MICW41
Support
User manual
Warranty
Support
2 AA Batteries (included) CE0678!
Compare

Features

  • with 2 wireless microphones
  • CPU control
  • dual 8 channels (tunable)
  • LCD display

Specifications

  • system:
    • frequency range: UHF 863.000 - 865.000 MHz (tunable)
    • A licence may be required for some frequency bands. Check your local regulations.
    • modulation mode: FM (PLL)
    • nominal / peak deviation: ± 25 kHz / max. ± 48 kHz
    • frequency stability: max. ± 15 ppm
    • frequency response: 60 Hz - 18 kHz
    • S/N ratio at 1mV RF and peak deviation: max. 110 dB(A)
    • THD at nominal deviation and 1kHz: max. 1%
    • temperature range: -10°C ~ + 55°C
  • receiver:
    • sensitivity (peak deviation): 3uV (52dB S/N)
    • AF output voltage at peak deviation and 1kHz AF out:
      • balanced: +10 dB (XLR)
      • unbalanced: +4 dB (1/4" jack)
    • F/N ratio: max. 80 dB
    • P/N ratio: max. 80 dB
  • transmitter:
    • RF output power: 1 mW
    • RF squelch: max. 50dB
  • power supply:
    • receiver: 14 VDC / 500 mA (adapter incl.)
    • transmitter: 2 x 1.5 V AA batteries (incl.)
  • dimensions:
    • receiver: 420 x 180 x 42 mm
    • transmitter: Ø50 x 275 mm
  • weight:
    • receiver: 1.9k g
    • transmitter: 410 g

All registered trademarks and trade names are properties of their respective owners and are used only for the clarification of the compatibility of our products with the products of the different manufacturers.
Due to constant product improvements the actual product appearance might differ from the shown images. Product images are for illustrative purposes only.
